1000 SERIES RIGOL DIGITAL OSCILLOSCOPES
DS1000B series oscilloscopes are designed with
four analog channels and 1 external trigger
channel, which can capture multi-channel signal
simultaneously and meet industrial needs.
The powerful trigger and analyzer abilities make
it easy to capture and analyze waves. Clear LCD
displays and math operations enable users to
view and analyze signal faster and more clearly
IN STOCK
Description
Four analog channels, 200MHz maximum
bandwidth, 2GSa/s maximum real-time
sample rate, 50GSa/s maximum equivalent
sample rate
5.7 inch, QVGA (320×240), 64K colors TFT
LCD and LED backlight source technology
enable the wave displays more vivid with
lower power dissipation and longer life
Conform to LXI consortium instrument
standard class C, which enable to create
and reset testing system fast, economically
and efficiently
Abundant trigger types: Edge, Pulse Width,
Video, Pattern and Alternative triggers
Unique adjustable trigger sensitivity enables
to meet different demands
Enable to measure 22 types of wave
parameters and track measurements via
cursor automatically
Unique waveform record and replay
function
Fine delayed scan function
Built-in FFT function, hold practical digital
filters
Pass/Fail detection function
Math operations available to multiple waves
Powerful PC application software UltraScope
Standard configure interface: USB Device,
Dual USB Host, LAN, support USB storage
device storage and PictBridge print standard
Support for remote command contro
